Product Overview and Specifications
14
Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver
Wallplate TX and Decor Wallplate TX Front LEDs
* The LEDs for Digital Video, Analog Video, and Audio each indicate the configured state of the connectors,
not necessarily the presence of signals through the Wallplate TX and Decor Wallplate TX.
Note: Detailed behavior for the NetLinx-L and NetLinx-S LEDs on the Wallplate TX or Link/Act and
Status LEDs on the Decor Wallplate TX are on page 61, and basic information for the LEDs on the
RJ-45 connector on the rear of the Wallplate TX and Decor Wallplate TX is on page 48.
Tip: If the Wallplate TX is installed in a location where it is difficult to check the LEDs on the bottom
edge, slide a white piece of paper or a small mirror under the edge to view LED status.
Wallplate TX and Decor Wallplate TX Indicator LEDs
LEDs Normal Display Indicates
Digital Video
(default)
Green The Wallplate TX and Decor Wallplate TX have been configured*
to pass HDMI (for SEND_COMMAND information, see page 86)
Analog Video One of the 3 LEDs
will be Green
The Wallplate TX and Decor Wallplate TX have been configured*
to pass one of the following types of analog video (for
SEND_COMMAND information, see page 86):
• C (composite) or Y/c (two component)
• Y/PB/PR or RGB (three component)
• RGBHV (five component) or RGBS (four component)
Audio Green The Wallplate TX and Decor Wallplate TX have been configured*
to pass analog audio as the audio source being embedded on the
DXLink output connection (coupled with either the analog or digital
video input path); for SEND_COMMAND information, see page 90
Power Green Power (from switcher) is applied to the unit
LEDs (bottom edge of Wallplate TX)
NetLinx - L (Link) Green Active LAN connection to an AMX Network
(Blinking = #3 Toggle OFF)
NetLinx - S (Status) Green
Off
• Speed status is 100 Mbps
• Speed status is 10 Mbps
DXLink Yellow Yellow
Flashing
Off
• Authenticated HDCP (handshaking has occurred successfully)
• Video is active; no HDCP
• No Video
DXLink Green Green DXLink connection is established
LEDs (under customer provided front cover plate on Decor Wallplate TX)
HDCP (DXLink) Yellow
Flashing
Off
• Authenticated HDCP (handshaking has occurred successfully)
• Video is active; no HDCP
• No Video
DXLink Green DXLink connection is established
Status (NetLinx) Green
Off
• Speed status is 100 Mbps
• Speed status is 10 Mbps
Link/Act (NetLinx) Green Active LAN connection to an AMX Network
(Blinking = #3 Toggle OFF)
