Product Overview and Specifications

Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver

* Interlaced video is supported into the Transmitters; progressive is only supported out of the Receiver unless it is

in Scaler Bypass mode.

AMX reserves the right to modify its products and their specifications without notice.

Analog Video Specifications

DXLink Multi-Format TX, Multi-Format Wallplate TX, and Decor Wallplate TX

Compatible Formats • RGBHV, RGBS, RGsB

• Y/Pb/Pr (HDTV)

• Y/c (S-Video), C (Composite)

Progressive Resolution Support 480p up to 1920x1200 @ 60 Hz

Interlaced Resolution Support* 480i, 576i, 1080i

Auto-Adjust Input Supported

RGB Input Signal Level Range 1 Vpp nominal

RGB Input Impedance 75 ohm

HV Sync Input Signal Level Range 2 to 5 Vpp

HV Sync Input Impedance 2.5 pF typical, 10 pF max.

Digital Processing 24 bit, 165 MHz

Y/Pb/Pr Input Signal Level Range • 1.0 Vpp for Y

• 700 mVpp for Pb, Pr

Y/Pb/Pr Input Impedance 75 ohm

Y/c (S-Video) Input Signal Level Range • 1.0 Vpp for Y

• 1.0 Vpp for c

Y/c (S-Video) Input Impedance 75 ohm

C (Composite) Input Signal Level Range 1.0 Vpp

C (Composite) Input Impedance 75 ohm

Connector HD-15 (breakout cable required for non-RGB formats)
