Installation and Setup
36
Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver
Options for System Setup with Enova DGX DXLink Boards
The following table contains options for using DXLink Transmitters and Receivers in conjunction with
DXLink Twisted Pair Input and Output Boards in an Enova DGX Digital Media Switcher.
* If the board is an SC Optical Board in an Enova DGX Digital Media Switcher, it will need the appropriate
DGX Fiber Module. For information, see the DGX Fiber Module’s Instruction Manual.
Options for System Setup with Enova DVX Solutions
The following table contains options for using DXLink Transmitters and Receivers in conjunction with
DXLink Input and Output connectors on Enova DVX Solutions. Note that on the input side, four
Transmitter options are available. The Transmitters used with the inputs can be of the same type or
different, depending on the installation needs.
Unless otherwise indicated, the Enova DVX Solutions in the table below have 2 DXLink input and/or
output connectors.
** These Enova DVX models have 1 DXLink output connector each.
System Setup Options – Enova DGX DXLink Boards with DXLink Transmitters/Receivers
DXLink Module/Wallplate Input Board Output Board DXLink Module
HDMI TX Module DXLink Twisted Pair DXLink Twisted Pair HDMI RX Module
HDMI TX Module DXLink Twisted Pair Any board* Not applicable
Multi-Format TX Module DXLink Twisted Pair DXLink Twisted Pair HDMI RX Module
Multi-Format TX Module DXLink Twisted Pair Any board * Not applicable
Multi-Format Wallplate TX DXLink Twisted Pair DXLink Twisted Pair HDMI RX Module
Multi-Format Wallplate TX DXLink Twisted Pair Any board* Not applicable
Decor Wallplate TX DXLink Twisted Pair DXLink Twisted Pair HDMI RX Module
Decor Wallplate TX DXLink Twisted Pair Any board* Not applicable
Not Applicable Any board* DXLink Twisted Pair HDMI RX Module
System Setup Options – Enova DVX DXLink Solutions with DXLink Transmitters/Receivers
DXLink Module/Wallplate Options Enova DVX Solution DXLink Module
...................................................
DVX-3155HD
DVX-2155HD**
..........................
HDMI TX Module
Multi-Format TX Module
Multi-Format Wallplate TX
Decor Wallplate TX
DXLink
Input connector
DXLink
Output connector
HDMI RX Module
...................................................
DVX-3150HD
..........................
NA NA DXLink
Output connector
HDMI RX Module
...................................................
DVX-2150HD**
...........................
NA NA DXLink
Output connector
HDMI RX Module
