AMX DXLink User Manual

Network Configuration
71
Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver
ID Pushbutton Boot State and LED Behavior
To monitor the ID Pushbutton boot state of a module by its LEDs, check both the Link/Act and Status
LED columns.
ID Pushbutton Boot and NetLinx LED Behavior
ID Pushbutton Boot States Link/Act LED Status LED
Boot with ID Pushbutton held down Slow blink (1 Hz) Slow blink (1 Hz)
ID Pushbutton held down long enough
for reset to default parameters
Fast blink until ID Pushbutton is
released, then OFF
Fast blink until ID Pushbutton is
released, then OFF
ID Pushbutton held down long enough
for reset to default firmware image
Solid ON, transitions to OFF
once the unit completes writing
to flash and is ready to reboot
Solid ON, transitions to OFF
once the unit completes writing
to flash and is ready to reboot
In Auto ID mode Normal Blink (2 Hz)
ID Pushbutton held down long enough to
accept new ID
2 blinks, then normal 2 blinks, then normal
After boot: ID Pushbutton held down, but
not long enough for IP mode change
Slow blink (1 Hz) Slow blink (1 Hz)
After boot: ID Pushbutton held down long
enough for IP mode change
Fast blink, then OFF Fast blink, then OFF

AMX DXLink Specifications

General

Category	Receiver
Dimensions	Varies by model
Weight	Varies by model
HDCP Compliance	Yes
Video Input Signal	HDMI
Control	RS-232, IR, Ethernet
Input Connector	HDMI
Output Connector	HDMI
Operating Temperature	0° to 50° C
Humidity	10% to 90% non-condensing
Storage Temperature	-20° to 70° C
