AMX DXLink User Manual

NetLinx Programming of DXLink Transmitters and Receivers
87
Instruction Manual – DXLink™ Twisted Pair Transmitters/Receiver
Video SEND_COMMANDs (Transmitters), continued
VIDIN_RES_REF
Sets the resolution and
refresh rate of the video
through the Transmitter
(disable VIDIN_RES_AUTO
prior to sending).
Important: Send to Port 7 or Port 8.
Syntax:
SEND_COMMAND <DEV>,"'VIDIN_RES_REF-
<horizontal>x<vertical>,<rate>'"
Variables:
• horizontal = An integer value representing the horizontal.
• vertical = An integer value representing the vertical. May have an
additional qualifier such as 'i' or 'p'.
• rate = An integer value representing the refresh rate.
?VIDIN_PREF_EDID
Requests the preferred
resolution of the EDID source
for the VGA video input.
Note: This command applies
to all DXLink Transmitters
except the HDMI TX.
Important: Send to Port 8.
Syntax:
SEND_COMMAND <DEV>,"'?VIDIN_PREF_EDID'"
Example:
SEND_COMMAND dvMFTX,"'?VIDIN_PREF_EDID'"
Returns a COMMAND of the form:
VIDIN_PREF_EDID-<resolution,refresh>
VIDIN_PREF_EDID
Sets the preferred resolution
of the EDID source for the
VGA video input.
Note: This command applies
to all DXLink Transmitters
except the HDMI TX.
Important: Send to Port 8.
Syntax:
SEND_COMMAND <DEV>,"'VIDIN_PREF_EDID -
<resolution,refresh>'"
Variable:
• resolution,refresh = <for supported input resolutions and refresh rates, see
the tables starting on page 131.>
Examples:
SEND_COMMAND dvMFTX,"'VIDIN_PREF_EDID-1920x1080p,60'"
?VIDIN_EDID
Requests which EDID is
being presented to the source
on the video port addressed
by the D:P:S.
Important: Send to Port 8.
Syntax:
SEND_COMMAND <DEV>, "'?VIDIN_EDID'"
Example:
SEND_COMMAND VIDEO_INPUT_1,"'?VIDIN_EDID'"
Returns a COMMAND of the form:
VIDIN_EDID-<source>
See the VIDIN_EDID command for the potential sources.
VIDIN_EDID
Sets the EDID to be
presented to the source on
the video input port
addressed by the D:P:S.
Important: Send to Port 8 (or Port 7 - only for the last variable listed).
Syntax:
SEND_COMMAND <DEV>,"'VIDIN_EDID-<source>'"
Variables:
source = ALL RESOLUTIONS, USER EDID 1* (Port 8 only)
MIRROR OUT 1** (Port 7 only)
Example:
SEND_COMMAND VIDEO_INPUT_1,"'VIDIN_EDID-ALL RESOLUTIONS'"
* “USER EDID 1” must be written to the TX using DGX Configuration
Software (see page 147).
** The HDMI port mirrors downstream EDID of the connected DXLink device.
Tip: For troubleshooting purposes, “MIRROR OUT 1” can be sent to Port 7 of
the TX (or Port 6 of the RX), which effectively acts like a hotplug and refreshes
the EDID.
VIDIN_PREF_EDID

AMX DXLink Specifications

General

Category	Receiver
Dimensions	Varies by model
Weight	Varies by model
HDCP Compliance	Yes
Video Input Signal	HDMI
Control	RS-232, IR, Ethernet
Input Connector	HDMI
Output Connector	HDMI
Operating Temperature	0° to 50° C
Humidity	10% to 90% non-condensing
Storage Temperature	-20° to 70° C
