Anderson Group Self-loading Bale Carrier TSR-3450 – Operator's Manual 49
NOTE: Normally, the pusher frame returns automatically. If
this is not the case:
l Ensure you pushed the pusher frame to the
end;
l Ensure that the pusher frame’s travel limit
has been adjusted to the width of your bales
(section 4.4 Pusher Frame Stroke);
l Consult section 7.2 Common Problems.
If none of these solutions work, manually return the
pusher frame by pressing the button controlling the
pusher frame return (see Figure 20 - Control Lever
and Table 7 - Actions Associated with the Buttons).
13. Repeat the previous step until your load is complete.
NOTE: When a bale is on the rear supports, a red indicator
light located on the front of the carrier, comes on
(see Figure 26 – Full Load Indicator). You may then
add just two more bales to your load.
Do not activate the pusher frame when the red
indicator light is on.
Figure 26– Full Load Indicator
