Andritz MC - Changing the Front Lining

Medium-consistency pump MC
STANDARD, C-01-000000
Rev. 0, 2010.02.09 MAINTENANCE Kap.7 , Seite 20 of 22
GRZ-2698573-v1-Maintenance.FM
7.9.1 Changing the front lining
Changing Change the wear linings according to the following table:
DANGER
Limbs can be jammed or crushed during installation work.
Wear your personal protective apparel.
Step Activity
1 Remove pump unit according to Section 7.8.1
2 Remove bearing as per Section 7.8.2
3 Remove front lining (135.1) by detaching the hexagon nuts
(
920.3) from the suction branch (153).
4 Remove stud bolts (902.3) from the front lining (135.3).
5 Change wear lining (135.1).
6 Re-assemble in reverse order.
7 The gap between the impeller (230.1) and the front lining
(
135.1) should be 1 +/- 0,3 mm (Fig. 7-8). This is obtained by
adding more seals (551.2) between the suction flange (153)
and the front lining (
135.1)
Tab. 7-16 Changing the front lining
