Medium-consistency pump MC
STANDARD, C-01-000000
Rev. 0, 2010.02.09 ERECTION WORK and TRANSPORT Kap.4 , Seite 10 of 12
GRZ-2698569-v1-Erection.FM
4.5.2 Pipework
When planning the pipework, a supplement must be included for heat
expansion.
Support Pipes should always be mounted stress-free. During erection work,
ensure that the pipes are supported in such a way that no forces,
vibrations or weight can be transferred to the pump.
3 Base frame
DANGER
... due to the medium-consistency pump falling or the
medium-consistency pump components being dropped during
transport to installation point.
Raise medium-consistency pump according to the transport
instructions in Chapter
4.3.
Do not step or walk below suspended loads.
DANGER
Limbs can be crushed or pinched during
installation.
Wear your personal protective apparel.
WARNING
Transport devices that are forgotten may result in risks to life and
limb and in damage to the machine.
Remove all transport devices.
Item Component Item Component
Tab. 4-2
DANGER
.. if pipework is not mounted professionally.
This can result in risks to life and limb and in damage to the
machine.
Under no circumstances should the medium-consistency pump be
used to support a pipe!
WARNING
If there is risk of dangerous backflow after the pump is shut down, a
reflux check device must be installed in the delivery pipe!
