7.7 Aligning the coupling
The coupling alignment must be checked after each of the following
assembly steps and corrected if necessary.
In particular:
• after mounting and before grouting in the pump
• after grouting in
• after installing the pipework
• after the trial run with water
If the alignment changes during production, the pump can also be aligned
at operating temperature.
Aligning
tolerances
Permitted tolerances
/MEDIUM CONSISTENCY PUMP MC/SUPPLIER
DOCUMENTATION/REXNORD
Abb. 7-1 Oil change
672
903.1
642
411.1
