Medium-consistency pump MC
STANDARD, C-01-000000
Rev. 0, 2010.02.09 DESCRIPTION Kap.3 , Seite 5 of 18
GRZ-2698568-v1-Description.FM
• Acid-resistant flange – chemical application (optional)
Pump shaft (211) Function: Holding the impeller, the fluidizer, the shaft seal, bearing
assembly and coupling. Transmitting the drive energy to the impeller and
thus, to the medium.
Design: Sturdily dimensioned drive shaft
Material: 1.4462
Impeller (230) Function: Accelerating the medium by charging it with energy.
Fig. 3-6 Acid-resistant flange – chemical application
Hastelloy
Tantalum
Fig. 3-7 Pump shaft
Pump shaft (211)
