Medium-consistency pump MC
STANDARD, C-01-000000
Rev. 0, 2010.02.09 DESCRIPTION Kap.3 , Seite 12 of 18
GRZ-2698568-v1-Description.FM
3.5 Standpipe
Function: Storage tank for centrifugal pump
Design: Please refer to the assembly drawing for details.
Components:
• Level measurement
• Connection Drainage
• Connection Flushing
• Overflow
Fig. 3-15 Standard standpipe
Fig. 3-14 Standpipe
Standpipe
With or without
expansion joint
Dilution water
connection
Drainage connection
bottom dilution connection
eyes for lifting the standpipe
