“beep” when the limit value is exceeded. To permit use in low-light en-
vironments, the LCD can be back lit using a front panel key.
Standard Accessories
A PC based software program (called Software Tools) provides an on-
line database record for storing measurement data. Site Master Soft-
ware Tools can also convert the Site Master display to a Microsoft
Windows 95 or Windows 3.x graphic. Measurements stored in the Site
Master internal memory are down-loaded to the PC using the included
serial cable. This null-modem serial cable connects between the Serial
Interface connector on the Site Master and a Com Port on a DOS/
Windows-based PC. Once stored, the graphic trace can then be dis-
played, scaled, and/or enhanced with markers and limit lines. Historical
graphs can be overlaid with current data by using the PC’s mouse in
“drag-n-drop” fashion. The underlying data can be extracted and used
in spreadsheets or for other analytical tasks.
The Software Tools program also performs DTF (Distance To Fault) or
Fault Location and Smith Chart by clicking on the appropriate icon.
The following items are supplied with the basic hardware.
•
Soft Carrying Case
•
AC-DC Adapter
•
Automotive Cigarette Lighter 12 Volt DC Adapter
•
3 1/2-inch floppy disk containing the Software Tools program.
This program contains Fault Location (DTF) and Smith Chart
functions
•
Serial Interface Cable (Null Modem Type)
•
One year Warranty (includes battery, firmware, and software)
•
User’s Guide
1-2
Chapter 1 General Information
