Step 7. Enter the desired numerical value using the keypad or
the Up/Down Arrow key. Press ENTER when data
entry is complete.
Step 8. Check that the FREQ (GHz) scale in the display area
indicates the new frequency start and stop values.
Performing a Calibration
Step 9.
Perform a measurement calibration using the START
CAL key. Select either COAX or WAVEGUIDE
calibration type. Select the desired setup configura-
tion fromthe following menu. Once setup is com-
plete, select START CALIBRATION from the menu
and press ENTER.
For COAX:
Follow the ensuing “Connect OPEN, Press EN-
TER,” Connect SHORT, Press ENTER,” and
“Connect LOAD, Press ENTER” instructions that
appear in the message area. Connect the respective
Open, Short, and Load components to the end of
theTest Port Extension Cable (Figure 2-8, page 2-26)
prior to pressing ENTER.
After each selection, the message “Measuring
OPEN,” “Measuring SHORT,” or “Measuring
LOAD” appears while the measurement is in prog-
ress.
For WAVEGUIDE:
Follow the ensuing “Connect SHORT 1, Press
ENTER,” “Connect SHORT 2, Press ENTER,”
and “Connect LOAD, Press ENTER” instructions
that appear in the message area. Connect the repec-
tive Short 1, Short 2, and Load components to the
end of the Test Port Extension Cable (Figure 2-8)
prior to pressing ENTER.
2-36
Chapter 2 Operation
