Adjusting Markers
Step 13.
Press the MARKER key (Figure 2-1, page 2-0) to
call up the Markers Menu. (Maximum of 4 available
markers)
Step 14.
Press the M1 soft key on the Markers Menu to select
Marker 1. This will open the Markers 2nd Level
Menu. Press the ON/OFF soft key to turn M1 on.
Press the EDIT soft key to open the M1 parameter
for data entry. Enter the desired numerical value us-
ing the keypad or the Up/Down Arrow key (Figure
2-1, page 2-0). Press ENTER when the data entry is
complete.
Step 15.
Press the BACK soft key to return to the Markers
Menu.
Step 16.
Press the M2 soft key on the Markers Menu to select
Marker 2. This will open the Markers 2nd Level
Menu. Press the ON/OFF soft key to turn M2 on.
Press the EDIT soft key to open the M2 parameter
for data entry. Enter the desired numerical value us-
ing the keypad or the Up/Down Arrow key (Figure
2-1, page 2-0). Press ENTER when the data entry is
complete.
Step 17.
Press the DELTA soft key to display the difference
between M2 and M1 in SWR (dB) and in frequency.
The delta function displays the difference of M2, M3,
or M4 with respect to M1.
Step 18.
Press the BACK and the MAIN soft key to return to
the Main Menu.
Adjusting a Limit
Step 19.
Press the LIMIT key (Figure 2-1, page 2-0) to call up
the Scale Menu.
