NOTES:
Changing D1, D2, Cable Type, Waveguide Type, Cut-
off Frequency, Propagation Velocity, and Loss within
the valid range will not invalidate the calibration. How-
ever; changing CF and/or D2 beyond its maximum
calibrated range or changing media type will require a
new calibration.
Press the
B5
soft key from the Option Sub-Menu
(page 2-14) to toggle between feet and meters. Val-
ues entered in either will freely convert to the other.
Loss and relative propagation velocity values for
many common cable types and cutoff frequency and
mid-band loss for many common waveguide types
are listed in the tables in Appendix A.
Scaling the Display
Step 7. The display can be scaled using either of the follow-
ing methods:
q Automatically scale the display using the AUTO
SCALE key (Figure 2-1, page 2-0).
q
Manually scale the display using the LIMIT key or
the SCALE soft key—from the Main Menu—and
the TOP and BOTTOM soft keys from the ensu-
ing soft key menu (page 2-12).
Adjusting Markers
Step 8.
Press the MARKER key (Figure 2-1, page 2-0) to
call up the Markers Menu (Maximum of 4 available
markers).
Step 9.
Press the M1 soft key on the Markers Menu to select
Marker 1. This will open the Markers 2nd Level
Menu. Press the ON/OFF soft key to turn M1 on.
2-45
Chapter 2 Operation
To Next Page
