Anritsu Site Master - Program Operation

Step 3. Observe that a “Waiting for Data” box appears on the
screen.
Step 4.
On the Site Master,
q
Capture a new trace and store it to a memory
location.
q
Recall the stored plot to the screen.
q
Press the ENTER key (on the Site Master) to start
the screen capture.
NOTE: The ENTER key on the Site Master must be
pressed while the PC screen shows “Waiting for
Data” for the transfer of information to be complete.
Step 5. On the PC, observe that the “Waiting for Data” box
disappears and the trace capture process begins.
Within a short time, the Site Master trace will ap-
pear.
Program Operation
The captured trace on the PC can be scaled and have its limit line,
markers, and properties changed. (Select Plot Properties under the
View menu to make these changes.) The operation of the various
menus that allow these operations to be accomplished is straightfor-
ward. To read about the operation of the menus, refer to the on-line
help screens. They can be accessed from the Help menu, in the top
menu bar.
