Anritsu Spectrum Master MS2722C - 5-2 Opening the Spectrum Master Case

5-2 Opening the Spectrum Master Case Chapter 5 — Assembly Replacement
5-4 PN: 10580-00279 Rev. E MS272xC MM
Figure 5-4. SPA Analyzer PCB Assembly (Top) and Main PCB Assembly (Bottom)
Fan and Fan
Connector
Battery
Connector
Encoder PCB
and Connector
Main PCB
(Under shielding)
Spectrum Analyzer Assembly
(Specify Spectrum Master model)
Option 31 PCB
Top Connector Panel
(Replaced with the SPA Assembly)
Bend Tab Over Option 31 Cable
and Encoder Wires
