A-3 Test Records for Options Verification Appendix A — Test Records
A-52 PN: 10580-00279 Rev. E MS272xC MM
Option 67 Mobile WiMAX Demodulator
MS272__C Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-122. Option 67, Mobile WiMAX Residual EVM (10 MHz Bandwidth and 10 ms Frame Length)
Frequency Power BW EVM (rms) Specification
2600.5 MHz –15 dBm 10 MHz % ≤ 3.0 %
2600.5 MHz –50 dBm 10 MHz % ≤ 3.0 %
3600.5 MHz –15 dBm 10 MHz % ≤ 3.0 %
3600.5 MHz –50 dBm 10 MHz % ≤ 3.0 %
Table A-123. Option 67, Mobile WiMAX Frequency Error (10 MHz Bandwidth and 10 ms Frame Length)
Frequency Power Frequency Error Specification
2600.5 MHz –50 dBm Hz ± 10 Hz
3600.5 MHz –50 dBm Hz ± 10 Hz
Table A-124. Option 67, Mobile WiMAX Residual EVM (5 MHz Bandwidth and 5 ms Frame Length)
Frequency Power BW EVM (rms) Specification
2600.5 MHz –15 dBm 10 MHz % ≤ 3.0%
2600.5 MHz –50 dBm 10 MHz % ≤ 3.0%
3600.5 MHz –15 dBm 10 MHz % ≤ 3.0%
3600.5 MHz –50 dBm 10 MHz % ≤ 3.0%
Table A-125. Option 67, Mobile WiMAX Frequency Error (5 MHz Bandwidth and 5 ms Frame Length)
Frequency Power Frequency Error Specification
2600.5 MHz –50 dBm Hz ± 10 Hz
3600.5 MHz –50 dBm Hz ± 10 Hz
