1-3 Recommended Test Equipment Chapter 1 — General Information
1-2 PN: 10580-00279 Rev. E MS272xC MM
1-3 Recommended Test Equipment
The following test equipment is recommended for use in testing and maintaining Anritsu Models MS2722C,
MS2723C, MS2724C, MS2725C, and MS2726C.
• Table 1-1 is a list of test equipment that is required for verifying the spectrum analyzer functions on
Models MS2722C, MS2723C, and MS2724C.
• Table 1-2 is a list of test equipment that is required for verifying the spectrum analyzer functions on
Models MS2725C, and MS2726C.
• Table 1-3 is a list of test equipment that is required for verifying the functions of installed options on any
MS272xC Model.
• Table 1-4 is a list of replaceable parts for the MS272xC Spectrum Master.
a. Note that MG3692A models require Option 15 to achieve power of +16 dBm at 3.5 GHz. MG3692B models do not require
Option 15 to achieve power of +16 dBm at 3.5 GHz.
Table 1-1. Test Equipment Required for Verifying Spectrum Analyzer Functions up to 20 GHz
Instrument Critical Specification Recommended Manufacturer/Model
Synthesized Signal Generator Frequency: 0.1 Hz to 20 GHz
Power Output: +16 dBm
Step attenuator installed
Anritsu Model MG3692A or MG3692B
with Options 2A, 4, 22, 15x
a
Power Meter Power Range: –70 to +20 dBm Anritsu Model ML2438A
Power Sensor Frequency: 100 kHz to 18 GHz
Power Range: –67 to +20 dB
Anritsu Model MA2421D or SC7400
(Qty 2)
50 ohm Termination Frequency: DC to 18 GHz Anritsu Model 28N50-2
Adapter Frequency: DC to 20 GHz
N(m)-N(m), 50 ohm
Anritsu Model 34NN50A
Adapter Frequency: DC to 20 GHz
K(m)-N(f), 50 ohm
Anritsu Model 34RKNF50
RF Coaxial Cable Frequency: DC to 18 GHz
N(m)-N(f), 50 ohm
Anritsu Model 15NN50-1.5B (Qty 2)
Lowpass Filter Frequency: 50 MHz Anritsu Part Number 1030-96
Frequency Reference Frequency: 10 MHz Symmetricom RubiSource T&M
Signal Generator Agilent Model 8648D with Options 1ES
and 1EA
Fixed Attenuator 10 dB Attenuation Aeroflex/Weinschel Model 44-10 (Qty 2)
Fixed Attenuator 20 dB Attenuation Aeroflex/Weinschel Model 44-20 (Qty 2)
Fixed Attenuator 6 dB Attenuation Aeroflex/Weinschel Model 44-6 (Qty 2)
Fixed Attenuator 2 dB Attenuation Aeroflex/Weinschel Model 44-2 (Qty 2)
Power Splitter Frequency: DC to 18 GHz Aeroflex/Weinschel Model 1870A
Coaxial Cable BNC(m) to BNC(m), 50 ohm Any (Qty 2)
Caution
Factory tests have shown that the equipment that is listed above will provide satisfactory results at
20 GHz (the upper limit of the MS2724C) even though the chart above specifies 18 GHz
(per manufacturers specifications). Many Type N cables have excessive loss for testing the
spectrum analyzer section of the instrument up to 20 GHz. An SMA cable or K cable should
therefore be installed on the MG synthesizer for all spectrum analyzer tests on the MS2724C.
