Option 541 and Option 543 LTE Measurements
MS272__C Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-126. Option 541 and Option 543, LTE Channel Power Accuracy
Frequency
(MHz)
Input Power
(dBm)
Measured
Channel Power Error Specification
For Units with Option 541 Installed, Pattern E-TM_1-1_10M
750 –10
dBm dB
± 1.5 dB
750 –50
dBm dB
± 1.5 dB
2150 –10
dBm dB
± 1.5 dB
2150 –50
dBm dB
± 1.5 dB
For Units with Option 543 Installed, Pattern E-TM_1-1_20M
750 –10
dBm dB
± 1.5 dB
750 –50
dBm dB
± 1.5 dB
2150 –10
dBm dB
± 1.5 dB
2150 –50
dBm dB
± 1.5 dB
