Anritsu Spectrum Master MS2722C - Option 40, GSM;GPRS;EDGE RF Measurements (Continued

A-3 Test Records for Options Verification Appendix A — Test Records
A-36 PN: 10580-00279 Rev. E MS272xC MM
Option 40, GSM/GPRS/EDGE RF Measurements (Continued)
MS272__C Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-67. Option 40, At 1800 MHz, –10 dBm Level, TCH ALL Pattern (GSM)
Measurement Measured Value Specification
Adjusted Output Power dB –10 dBm ± 0.2 dB
Displayed Burst Power dB
Calculated Burst Power Error dB ± 1.5 dB
Frequency Error Hz ± 10 Hz
Table A-68. Option 40, At 1800 MHz, –50 dBm Level, TCH Pattern (GSM)
Measurement Measured Value Specification
Adjusted Output Power dB –10 dBm ± 0.2 dB
Displayed Burst Power dB
Calculated Burst Power Error dB ± 1.5 dB
Frequency Error Hz ± 10 Hz
Table A-69. Option 40, At 1800 MHz, –50 dBm Level, DL_MCS-9_1SLOT Pattern (EDGE)
Measurement Measured Value Specification
Adjusted Output Power dB –10 dBm ± 0.2 dB
Displayed Burst Power dB
Calculated Burst Power Error dB ± 1.5 dB
Frequency Error Hz ± 10 Hz
Table A-70. Option 40, At 1800 MHz, –10 dBm Level, DL_MCS-9_4SLOT Pattern (EDGE)
Measurement Measured Value Specification
Adjusted Output Power dB –10 dBm ± 0.2 dB
Displayed Burst Power dB
Calculated Burst Power Error dB ± 1.5 dB
Frequency Error Hz ± 10 Hz
