Anritsu Spectrum Master MS2722C - Option 552 and Option 543, TD-LTE Measurements

A-3 Test Records for Options Verification Appendix A — Test Records
A-56 PN: 10580-00279 Rev. E MS272xC MM
Option 552 and Option 543, TD-LTE Measurements
MS272__C Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-129. Option 552, TD-LTE Residual EVM and Frequency Accuracy
Measurement Measured Value Specification
For Units with Option 552 Installed, Pattern TDLTE-E-TM-3-3_10M
750 MHz at –12 dBm
Frequency Error Hz ± 10 Hz
EVM (rms) % < 2.0% typical
750 MHz at –30 dBm
Frequency Error Hz ± 10 Hz
EVM (rms) % < 2.0% typical
2350 MHz at –12 dBm
Frequency Error Hz ± 10 Hz
EVM (rms) % < 2.0% typical
2350 MHz at –30 dBm
Frequency Error Hz ± 10 Hz
EVM (rms) % < 2.0% typical
For Units with Option 543 Installed, Pattern TDLTE-E-TM-3-3_20M
750 MHz at –12 dBm
Frequency Error Hz ± 10 Hz
EVM (rms) % < 2.0% typical
750 MHz at –30 dBm
Frequency Error Hz ± 10 Hz
EVM (rms) % < 2.0% typical
2350 MHz at –12 dBm
Frequency Error Hz ± 10 Hz
EVM (rms) % < 2.0% typical
2350 MHz at –30 dBm
Frequency Error Hz ± 10 Hz
EVM (rms) % < 2.0% typical
