Chapter 1 — General Information 1-4 Replaceable Parts
MS272xC MM PN: 10580-00279 Rev. E 1-5
c. Note that MG3692A models require Option 15 to achieve power of +13 dBm. MG3692B models do not require Option 15 to
achieve +13 dBm power.
d Note that the MG3700A requires that several factory custom test pattern files be installed into its memory.
1-4 Replaceable Parts
GPS Antenna Anritsu 2000-1410
Coaxial Cable BNC(m) to BNC(m), 50 ohm Any
Adapter K(f) to N(f), 50 ohms, Ruggedized Anritsu Model 71693-R
Table 1-4. List of Replaceable Parts (1 of 2)
Part Number Description
ND72062 MS2722C Main PCB Assembly, with Option 9
e
ND72063 MS2723C Main PCB Assembly, with Option 9
e
ND72064 MS2724C Main PCB Assembly, with Option 9
e
ND72065 MS2725C Main PCB Assembly, with Option 9
e
ND72066 MS2726C Main PCB Assembly, with Option 9
e
ND72070 MS2725C and MS2726C Spec Analyzer PCB Assembly
ND72069 MS2724C Spec Analyzer PCB Assembly
ND72068 MS2722C and MS2723C Spec Analyzer PCB Assembly
ND70320 MS272xC GPS Receiver PCB (Option 31)
3-790-661 Gasket material for case edge
3-15-154 LCD Display
3-61368 Clear Plastic LCD Protector
2000-1685-R Soft Carrying Case
3-68100-1 Case Top (excludes model ID Label and keypad items)
3-61365-1 Case Bottom (excluding Tilt Bail)
ND69107 Case Bottom including Tilt Bail
3-65314 Left and Right Tilt Bail (Plastic) Holders
3-65316 Tilt Bail Stand (Metal)
3-65684 Tilt Bail (Plastic) Clip
3-68108 Model MS2722C ID Label
3-68107 Model MS2723C ID Label
3-68106 Model MS2724C ID Label
3-68105 Model MS2725C ID Label
3-68104 Model MS2726C ID Label
61379-1 Battery Door
633-75 High Capacity Li-ion Battery Pack
510-87 Type N RF Input connector
3-71353 Type K(m) Rugged RF Input connector
Table 1-3. Test Equipment Required for Verifying Functions of Installed Options (2 of 2)
Instrument Critical Specification Recommended Manufacturer/Model
