1-3 Recommended Test Equipment Chapter 1 — General Information
1-4 PN: 10580-00279 Rev. E MS272xC MM
Table 1-3. Test Equipment Required for Verifying Functions of Installed Options (1 of 2)
Instrument Critical Specification Recommended Manufacturer/Model
Synthesizer Frequency: 0.1 Hz to 20 GHz,
+16 dBm power
Anritsu Model MG3692A or MG3692B with
options 2A, 4, 15, and 22
c
Vector Signal Generator Frequency: 100 kHz to 3 GHz Anritsu Model MG3700A with Options
MG3700A-002 and MG3700A-021
d
Power Meter Power Range: –70 to + 20 dBm Anritsu Model ML2438A
Power Sensor Frequency: 10 MHz to 18 GHz
Power Range: –60 to +20 dBm
Anritsu Model MA2482D with Option 1 (Qty 2)
Frequency Counter Frequency: 20 GHz Anritsu Model MF2412B
Programmable Attenuator Frequency: DC to 2 GHz
Attenuation: 100 dB
(1 and 10 dB steps)
Anritsu Model MN63A
Fixed Attenuator Frequency Range:
DC to 18 GHz
Attenuation: 10 dB
Aeroflex/Weinschel Model 44-10 (Qty 2)
Power Splitter Frequency: DC to 18 GHz Aeroflex/Weinschel Model 1870A
RF Power Amplifier Frequency:100 to 1000 MHz
Gain: 35 dB min
Mini Circuits Model TIA-1000-1R8
(Qty 2 BNC(m) to N(f) Adapters required)
Adapter Frequency: DC to 20 GHz
N(m)-N(m), 50 ohm
Maury Microwave Model 8828B
Quantity: 2 each [One each required only if
Anritsu Coupler and Circulator are used]
Adapter Frequency: DC to 20 GHz
K(m)-N(f), 50 ohm
Anritsu Model 34RKNF50
Adapter Frequency: 881.5 MHz
BNC(m) to N(f), 50 ohm
Midwest Microwave Model
ADT-2615-NF-BNM-02 (Qty 2)
Adapter Frequency: 881.5 MHz
SMA(m) to N(f), 50 ohm
Midwest Microwave Model
ADT-2582-NF-SMM-02 (Qty: 4)
[Required only if Anritsu Coupler and Circulator
are used.]
Adapter Frequency: 881.5 MHz
SMA(m) to SMA(m), 50 ohm
Midwest Microwave Model
ADT-2594-MM-SMA-02
[Required only if Anritsu Coupler and Circulator
are used.]
50 ohm Termination Frequency: DC to 18 GHz Anritsu Model 28N50-2
High Power Load DC to 18 GHz, 10W Aeroflex/Weinschel Model M1418
Coupler Frequency: 881.5 MHz
Coupling Factor: 30 dB
Midwest Microwave Model
CPW-5140-30-NNN-05 or
CPW-5141-30-NNN-05
Alternative: Anritsu part number 1091-307
[Two SMA(m) to N(f) adapters required.]
Circulator Frequency Range:
800 to 1000 MHz
Isolation: 20 dB min
Meca Electronics, Inc. part number CN-0.900
Alternative: Anritsu part number 1000-50
[Two SMA(m) to N(f) adapter and
one SMA(m) to SMA(m) Adapter required.]
RF Coaxial Cable Frequency: DC to 18 GHz
N(m)-N(m), 50 ohm
Anritsu Model 15NN50-1.5B (Qty 3)
