Anritsu Spectrum Master MS2722C - Option 62, EVDO RF Measurements (Continued; Option 63 EVDO Demodulator

A-3 Test Records for Options Verification Appendix A — Test Records
A-48 PN: 10580-00279 Rev. E MS272xC MM
Option 62, EVDO RF Measurements (Continued)
Option 63 EVDO Demodulator
MS272__C Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-108. Option 62, At 870.03 MHz, –10 dBm Level, Idle Slot
Measurement Measured Value Specification
Power Meter Reading dBm –10 dBm ± 0.2 dB
MS272xC Reading dBm
Calculated Channel Power Error dB ± 1.5 dB
Table A-109. Option 63, At 870.03 MHz, –50 dBm Level, 921.6 kps 8PSK Modulation
Measurement Measured Value Specification
Frequency Error Hz ± 20 Hz
Rho Pilot 0.99 ≤ x ≤ 1
Tau μs± 1μs
Table A-110. Option 63, At 1930.05 MHz, 0 dBm Level, 38.4 kps QPSK Modulation
Measurement Measured Value Specification
Frequency Error Hz ± 20 Hz
Rho Pilot 0.99 ≤ x ≤ 1
Tau μs±1μs
