Anritsu Spectrum Master MS2722C - Option 66 Mobile Wimax RF Measurements (Continued

Appendix A — Test Records A-3 Test Records for Options Verification
MS272xC MM PN: 10580-00279 Rev. E A-51
Option 66 Mobile WiMAX RF Measurements (Continued)
Channel Power Accuracy (5 MHz Bandwidth and 5 ms Frame Length)
MS272__C Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-118. Option 66, Mobile WiMAX Channel Power Accuracy Power Error (2600.5 MHz and –15.0 dBm)
Measurement Measured Value Specification
Power Meter Reading dBm –15 dBm ± 0.2 dB
MS272xC Reading dBm
Calculated Channel Power Error dB ± 1.5 dB
Table A-119. Option 66, Mobile WiMAX Channel Power Accuracy Power Error (2600.5 MHz and –50.0 dBm)
Measurement Measured Value Specification
Power Meter Reading dBm –50 dBm ± 0.2 dB
MS272xC Reading dBm
Calculated Channel Power Error dB ± 1.5 dB
Table A-120. Option 66, Mobile WiMAX Channel Power Accuracy Power Error (3600.5 MHz and –15.0 dBm)
Measurement Measured Value Specification
Power Meter Reading dBm –15 dBm ± 0.2 dB
MS272xC Reading dBm
Calculated Channel Power Error dB ± 1.5 dB
Table A-121. Option 66, Mobile WiMAX Channel Power Accuracy Power Error (3600.5 MHz and –50.0 dBm)
Measurement Measured Value Specification
Power Meter Reading dBm –50 dBm ± 0.2 dB
MS272xC Reading dBm
Calculated Channel Power Error dB ± 1.5 dB
