Anritsu Spectrum Master MS2722C - Option 47 Fixed Wimax Demodulator; Option 60 or Option 61, TDSCDMA Signal Analyzer Option Verification

A-3 Test Records for Options Verification Appendix A — Test Records
A-46 PN: 10580-00279 Rev. E MS272xC MM
Option 47 Fixed WiMAX Demodulator
Option 60 or Option 61, TDSCDMA Signal Analyzer Option Verification
MS272__C Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-101. Option 47, Fixed WiMAX Residual EVM
Frequency Power BW EVM (RMS) Specification
2600.5 MHz –15 dBm 10 MHz % ≤ 3.5%
2600.5 MHz –50 dBm 10 MHz % ≤ 3.5%
3600.5 MHz –15 dBm 10 MHz % ≤ 3.5%
3600.5 MHz –50 dBm 10 MHz % ≤ 3.5%
5600.5 MHz –15 dBm 10 MHz % ≤ 3.5%
5600.5 MHz –50 dBm 10 MHz % ≤ 3.5%
Table A-102. Option 47, Fixed WiMAX Frequency Error
Frequency Power Frequency Error Specification
2600.5 MHz –50 dBm Hz ± 10 Hz
5600.5 MHz –50 dBm Hz ± 10 Hz
Table A-103. Option 60 or Option 61, TDSCDMA (at 2010 MHz, –45 dBm Level)
Measurement Type Measured Value Specification
Power Meter Reading dBm –45 dBm ± 0.5 dB
Displayed Channel Power dBm
Calculated Channel Power Error dB ± 1.5 dB
EVM % < 3 % typical
Frequency Error Hz ± 20 Hz
Tau μs±0.2μs
