Anritsu Spectrum Master MS2722C - Option 44 And;Or 45 And;Or 65 WCDMA and HSDPA RF Measurements (Continued

Appendix A — Test Records A-3 Test Records for Options Verification
MS272xC MM PN: 10580-00279 Rev. E A-43
Option 44 and/or 45 and/or 65 WCDMA and HSDPA RF Measurements (Continued)
MS272__C Firmware Rev: ______________ Operator: ____________________ Date: ____________
Serial Number: _______________ Options: __________________________________________________
Table A-93. Option 44, WCDMA RF Channel Power Accuracy
Frequency
Power Meter
Reading
Measured RF
Channel Power
RF Channel
Power Error Specification
881.5 MHz dBm dBm dBm ± 1.25 dBm max
1962.5 MHz dBm dBm dBm ± 1.25 dBm max
2680.5 MHz dBm dBm dBm ± 1.25 dBm max
Table A-94. WCDMA ACLR Accuracy
Frequency/Offset Measured ACLR Calculated ACLR Error Specification
881.5 / –10 MHz ±0.8dB
881.5 / –5MHz ±0.8dB
881.5 / 5 MHz ±0.8dB
881.5 / 10 MHz ±0.8dB
1962.5 / –10 MHz ±0.8dB
1962.5 / –5MHz ±0.8dB
1962.5 / 5 MHz ±0.8dB
1962.5 / 10 MHz ±0.8dB
2680.5 / –10 MHz ±1.0dB
2680.5 / –5MHz ±1.0dB
2680.5 / 5 MHz ±1.0dB
2680.5 / 10 MHz ±1.0dB
Table A-95. Option 44, HSDPA RF Channel Power Accuracy
Frequency Power Meter Reading
Measured RF
Channel Power
RF Channel Power
Error Specification
2680.5 MHz ±1.25dB max
