1-4 Replaceable Parts Chapter 1 — General Information
1-6 PN: 10580-00279 Rev. E MS272xC MM
e. When ordering the Main PCB Assembly, in order to ensure installation of correct options, all options that are installed on the
instrument must be declared on the order. The options are listed on a label on the top of the MS272xC and are also shown in the
System (Shift 8) / Status display.
ND70948 Fan
40-187-R AC to DC Power Converter
3-71027-3 Main Keypad PCB
3-61362 Main Keypad (Rubber)
3-61363-1 Main Keyboard Bezel
3-61361 Soft keys Keypad (Rubber)
3-61378-1 Soft key Bezel
3-71030-3 Soft key PCB
790-625 Speaker
3-410-101 Encoder (excluding knob)
3-61360-2 Knob (excluding encoder)
Table 1-4. List of Replaceable Parts (2 of 2)
Part Number Description
