Patient monitor User’s manual
Chapter 1-4
1. Physiological alarm indicating lamp
When a physiological alarm occurs, this lamp will light up as defined
below:
 High level alarm: the lamp quickly flashes red.
 Medium level alarm: the lamp slowly flashes yellow.
 Low level alarm: the lamp lights yellow without flashing.
2. Technical alarm indicating lamp
When a technical alarm occurs, this lamp will light up as defined below:
 Medium level alarm: the lamp slowly flashes yellow.
 Low level alarm: the lamp lights blue without flashing.
3. Display screen
4. Power button
5. Power indicating lamp
It is a LED that lights green and orange, the status of the LED is specified
as follows:
 Green: When the AC mains is connected.
 Orange: When the AC mains is not connected and monitor is powered
by battery.
 Off: When the AC mains is not connected.
6. Battery charging indicating lamp
 Light up: When the battery is being charged.
 Off: When the battery is fully charged or no battery in monitor.
7. Trim Knob
The Trim Knob is used for:
 Turn left or turn right to move the cursor.
 Press down to perform an operation, such as open a menu dialog or
select one option.
