Patient monitor User’s manual
Chapter 18-2
18.3 Monitoring Procedure
1. Connect the BISx equipment to the BIS module;
2. Fix the BISx equipment on an appropriate place near the patient. The place
should not be above the patients’ head;
3. Attach the BIS sensor to the patient according to the attached instructions
4. Connect the patient interface cable (PIC) to the BISx equipment;
5. Connect the BIS sensor to the patient interface cable (PIC). Once an
effective sensor is detected, the equipment will automatically measure the
impedance of all electrodes and measurements will be shown in the BIS
Make sure that the BISx equipment does not contact the patient's skin
for a long time because the equipment will generate heat, causing
Please make sure that the patient's skin is dry because a wet sensor or
salt bridge may cause wrong BIS and resistance values.
After the BISx equipment and BIS module are connectted, make sure
that the connection of BISx will not happen again. When the BISx
cable need be disconnected from the BIS module, carefully hold the
connector and then pull it out, rather than pull and drag the cable.
18.4 BIS Display
BIS module can be used to monitor parameters such as BIS, SQI, EMG,
SR, SEF, TP, BC, and so on. You can open【Module Set】, select BIS Module,
and then start or close the BIS module by selecting the On/Off button. After
the BIS module is opened, an EEG waveform, a trend chart, and BIS
parameters will be displayed on the screen as follows.
