Patient monitor User’s manual
Chapter 7-9
Note:Under the mode of 【 Surgery】 and【Monitor】,the state of the
filter cannot be regulated. Only under the state 【 Diagnosis 】 of
【
User
】
can the state be regulated. Please select
【
Monitor
】
during monitoring a patient, select
【
Surgery
】
under the state of
great interference.
 Setting QRS Volume
The monitor will give out QRS sound according to HR value. Select
【
QRS
Volume
】
in the ECG setting menu to change the QRS volume. The volume can
be set to a value from【1】to【10】and also can be 【Silence】.
 Setting the Primary Lead
Select【Primary Lead】in ECG parameter setting menu, and you can set
the primary lead as required, the wave of primary lead will be displayed on
the top of the screen.
 Setting Wave Gain
If ECG wave on the screen is too small or be cut much, you shall select
【Wave Gain】in the ECG setting menu to change the amplitude of ECG wave.
The options are【Auto】,【0.25×】,【0.5×】,【1.00×】,【2.00×】and【4.00×】.When
selecting 【 Auto 】 , the monitor will adjust the amplitude of ECG wave
automatically.
 Setting Wave Speed
Select 【 Wave Speed 】 in the ECG setting menu, and select proper sweep
speed in the options.
7.6 ST Monitoring
The monitor performs ST segment analysis on normal and atrially paced
beats and calculates ST segment elevations and depressions.
ST segment monitoring is not applicable to neonates.
The clinical significance of the ST segment analysis should be determined
by a physician.

