Chapter 10:
STANDARD 365-095-33577 Revision x.1 IPC4100 Release 1.0 Installation and Operation Guide
48
Field Description
MRL PID PID of the MRL file in the DSMCC carousel, if available.
MRL Url Web address for accessing the MRL file.
MRL IPMC Join Interval Interval (in minutes) for the product to join the MRL
Multicast address for downloading the MRL file, if available.
Next MRL IPMC Join Time Scheduled data and time when the product is expected
joined the MRL multicast, if available.
Last Successful MRL IPMC
Join Time
Time when the product last successfully joined the MRL
multicast, if available.
MRL Error Indicates the error (DLxx format), if any, that occurred
during the download:
DL00 - No-error
DL21 - Invalid MRL source
DL22 - Unable to join MRL multicast
DL23 - Failed to authenticate MRL file
DL24 - Invalid MRL file
DL25 - Unable to parse MRL
DL26 - MRL without matching target type
DL27 - MRL missing campaign for target type
MRL Download Trigger Allows you to select an immediate MRL Unicast or Multicast
download.
From the MRL Information screen, press the INFO key on
the remote to enable a trigger for an immediate MRL
download including any associated code object download.
Once the trigger is enabled, use the right/left arrow keys to
select the download method: Multicast, Unicast, or No
Trigger to cancel. Press OK to activate the trigger.
Note: The No Trigger option disables the MRL Download
Trigger.
Table 7. Code Modules – Card Download Fields
Field Description
MCard Download Channel Download channel configured for the M-Card Object
MCard DL PID Download PID detected for the M-Card Object
MCard DL Segment Count Download segment count, if M-Card object is in the process of
downloading.
MCard DL Status Download status from M-Card:
