Chapter 10:
STANDARD 365-095-33577 Revision x.1 IPC4100 Release 1.0 Installation and Operation Guide
49
Field Description

0x00 Idle
 0x01 WaitDLPID
 0x02 WaitSeg0
 0x03 Loading
 0x04 AuthStor
 0x05 WaitEnabl
 0x06 WaitReset
MCard DL Error  0x00 None
 0x01 Segment 0 timeout
 0x02 Header CRC error
 0x03 Image CRC error
 0x04 Image authentication error
 0x05 Flashing error
 0x06 Object enable timeout
 0x07 Done and waiting for reset
 0x08 Wrong image version
 0x09 Host busy
 0x0A Host did not find download PID
MCard Object Name M-Card object name of the object being downloaded.
MCard Object Version M-Card object version of the object being downloaded.
Note: Additional Host Object Table pages will display as the number of software objects
increases.
Table 8. Code Modules – Host Object Table Fields
Field Description
Object Name Name of the software object loaded or downloading onto the
set-top.
Object Version Version of the software object loaded / downloading onto the
set-top.
Object Size Indicates the object size.
Status
Status of the object download, expressed as a text string, which may
include:
 Available
 Download-in-progress
 Download-Completed
