Field Description
port: Yes or No.
Video Xmission Video transmission — Indicates whether the IPC4100 is
transmitting video over the HDMI port
HDCP Enabled Indicates whether the IPC4100 is using HDCP to encrypt
video transmitted over the HDMI link — Yes or No. If the
Video Xmission status is Not Active, the HDCP Enabled status
is No
output Format Indicates the timing format of the video sent through HDMI:
 1920 x 1080p — 1920 pixels wide by 1080 pixels high,
progressive
 1920 x 1080i — 1920 pixels wide by 1080 pixels high,
interlaced
 1280 x 720p — 1280 pixels wide by 720 pixels high,
progressive
 720 x 480p — 720 pixels wide by 480 pixels high,
progressive
 720 x 480i — 720 pixels wide by 480 pixels high,
interlaced
 640 x 480p — 640 pixels wide by 480 pixels high,
progressive
Aspect Ratio Indicates the aspect ratio of the video sent through HDMI:
4:3 or 16:9.
EDID DATA Indicates the video timing formats that were read from the
Extended Display Identification Data (EDID) register for the
connected device. In particular, the detailed timing
description blocks. The list displays a selection of common
formats that the TV or repeater supports that have been
read by the Product.
If the Product cannot read any formats, EDID Data is blank.
An asterisk (*) after the aspect ratio indicates the Product
supports the format.
Table 14. User Setting Fields (Page 2 of 2)
Field Description
TV Type Indicates how the style of television connected to the
product was set (16:9 or 4:3) and the preferred content
control method (for example, Letterbox, pan and scan,
undistorted)
 16:9 designates that a widescreen television is
connected to the set-top.

4:3 LETTERBOX designates that a standard screen
