Field Description
television is connected to the RCM set-top and that
widescreen programs should be scaled to fit the screen
with black bars above and below the picture.
 4:3 PAN SCAN designates that a standard screen
television is connected to the RCM set-top and that
widescreen programs should be cropped so that the
picture fills the entire screen.
Output Type Displays the video output format of the RCM set-top for all
content (when the 4:3 override setting is OFF) or for all
480p, 720p, and 1080i content (when the 4:3 override is
used).
Possible options:
 1080p60 — High-Definition 1080p, 60 fps format (1920 x
1080 pixels).
 1080i — (Default option) High-Definition 1080i format
(1920 x 1080 pixels).
 720p — High-Definition 720p format (1280 x 720 pixels)
 480p — Enhanced-Definition 480p format (720 x 480
pixels).
 480i —Standard-Definition 480i format (720 x 480
pixels).
1080p Passthrough
Enabled
Shows whether the passthrough of 1080p2 is turned On or
Off.
Closed Caption Enabled Indicates if closed captions is turned ON or OFF. The front
panel display indicates the status of the closed captions.
Possible options: Yes or No (default)
CC Analog Service
Selection
Shows the analog service used for closed captions.
Possible options: CC1 (default), CC2, CC3, CC4, T1, T2, T3, or
T4
CC Digital Service
Selection
Shows the digital service used for closed captions:
 D1 - PRIMARY LANGUAGE (default)
 D2 - SECONDARY LANGUAGE
 D3, D4, D5, or D6
Detection of 3DTV
Primary Formats
Indicates if the 3D video timing formats are read from the
Extended Display Identification Data (EDID) register for the
connected device.
Side by Side Indicates if 3D ‘Side by Side was detected: Yes or No
Top Bottom Indicates if 3D ‘Top Bottom’ was detected: Yes or No
