Board
Reference
FPGA Pin
No.
CRUVI HS
No
Pin
Func.
Description
I/O Std
A2_N
PIN_A15
28
Output
High-Speed Differential
Transmitter A[2]_n
1.8 V /
3.3 V
A3_P
PIN_A16
32
Output
High-Speed Differential
Transmitter A[3]_p
1.8 V /
3.3 V
A3_N
PIN_A17
34
Output
High-Speed Differential
Transmitter A[3]_n
1.8 V /
3.3 V
A4_P
PIN_F9
38
Input
High-Speed Differential Receiver
A[4]_p
1.8 V /
3.3 V
A4_N
PIN_F10
40
Input
High-Speed Differential Receiver
A[4]_n
1.8 V /
3.3 V
A5_P
PIN_B7
44
Input
High-Speed Differential Receiver
A[5]_p
1.8 V /
3.3 V
A5_N
PIN_B8
46
Input
High-Speed Differential Receiver
A[5]_n
1.8 V /
3.3 V
B0_P
PIN_B17
15
Output
High-Speed Differential
Transmitter B[0]_p
1.8 V /
3.3 V
B0_N
PIN_B18
17
Output
High-Speed Differential
Transmitter B[0]_n
1.8 V /
3.3 V
B1_P
PIN_A7
21
Output
High-Speed Differential
Transmitter B[1]_p
1.8 V /
3.3 V
B1_N
PIN_A6
23
Output
High-Speed Differential
Transmitter B[1]_n
1.8 V /
3.3 V
B2_P
PIN_C13
37
Input
High-Speed Differential Receiver
B[2]_p
1.8 V /
3.3 V
B2_N
PIN_C12
29
Input
High-Speed Differential Receiver
B[2]_n
1.8 V /
3.3 V
B3_P
PIN_E8
33
Input
High-Speed Differential Receiver
B[3]_p
1.8 V /
3.3 V
B3_N
PIN_F7
35
Input
High-Speed Differential Receiver
B[3]_n
1.8 V /
3.3 V
B4_P
PIN_G6
39
Input
High-Speed Differential Receiver
B[4]_p
1.8 V /
3.3 V
B4_N
PIN_F6
41
Input
High-Speed Differential Receiver
B[4]_n
1.8 V /
3.3 V
B5_P
PIN_B4
45
Input
High-Speed Differential Receiver
B[5]_p
1.8 V /
3.3 V
B5_N
PIN_B5
47
Input
High-Speed Differential Receiver
B[5]_n
1.8 V /
3.3 V
HSI
PIN_D16
10
Bidir
Serial In or High-Speed Differential
Transmitter A[6]_p
1.8 V /
3.3 V
HSMIO
PIN_C16
2
Bidir
Serial Data I/O or High-Speed
Differential Transmitter A[6]_n
1.8 V /
3.3 V
HSO
PIN_B14
6
Output
Serial Out or High-Speed
Differential Transmitter A[7]_p
1.8 V /
3.3 V
HSRST
PIN_B15
8
Output
Serial Reset or High-Speed
Differential Transmitter A[7]_n
1.8 V /
3.3 V
SMB_ALERT
PIN_G17
3
Input
SMBus interrupt signal
3.3 V
SMB_SDA
PIN_H18
5
Bidir
SMBus Data Line
3.3 V
SMB_SCL
PIN_F17
7
Output
SMBus Data Clock Line
3.3 V
