Introduction to the CYC5000 Board
2.1 Layout and Components
Figure 1 shows the top view of the board. It depicts the layout of the board and indicates the
location of the various connectors and key components.
The following features are available on the CYC5000 board:
• Intel Cyclone V 5CEBA2U15C8N device
• Arrow USB Programmer2 on-board for programming; JTAG Mode
• 64Mbit SDRAM up to 166MHz
• 64Mbit QSPI Configuration flash memory
• CRUVI HS Connector
• USB-to-JTAG
• GPIO-FTDI
• Arduino MKR Header
• 12MHz MEMS Oscillator
• 8 red user LEDs
• 2 board indicaton LEDs
• 2 user push buttons
