CYC5000 User Guide www.arrow.com
Page | 20 March 2023
Board
Reference
FPGA Pin No.
Pin Func.
I/O Std
LED1
PIN_P4
Output
3.3 V
LED2
PIN_M4
Output
3.3 V
LED3
PIN_M3
Output
3.3 V
LED4
PIN_N3
Output
3.3 V
LED5
PIN_V2
Output
3.3 V
LED6
PIN_T2
Output
3.3 V
LED7
PIN_L1
Output
3.3 V
LED8
PIN_K1
Output
3.3 V
3.3.7 Push Buttons
The board has two push buttons connected to the FPGA. Push buttons drive their associated pins
low logic level when pressed and high logic level when released.

























Figure 11 LED Connections
