Installation Manual
NU-Series Hardware
IP Devices
5.3.1 NISM2 Electrical Connections
The following figure shows the electrical connections on the back of the NISM2.
Figure 25 NISM2 electrical connections
Legend:
(1) COM Ports
(2) Ethernet LAN for facility
(3) External Power
5.3.2 Ethernet LAN Cable for Facility Network
Connect the Ethernet LAN cable to the “LAN 1” port.
Figure 26 Connecting the Ethernet LAN cable
Legend:
(1) 10baseT/100base T Ethernet LAN Connection
