4.3.4. Default Test Parameters
Each of the test types (AC withstand, DC withstand and IR) have specific default test
parameters that automatically load when test type is selected from the parameter edit screen.
The following table is a listing of the Default Parameters for each of the different types of tests
that are available in the Hypot III. The Default Parameters are as follows:
Test Type
Parameter
Value
ACW
Voltage
1,24kV
Max Lmt (current) 10.00mA
Min Lmt (current) 0.000mA
Ramp UP 0.1s
Dwell 1.0s
Ramp DN 0.0s
Arc Sense 0
Frequency 60Hz
Continuity OFF
Max Lmt (Continuity)
1.00
Ω
Min Lmt (Continuity)
0.00
Ω
Offset (Continuity)
0.00
Ω
Connect OFF
DCW
Voltage
1,50kV
Max Lmt (Current)
5000
µ
A
Min Lmt (Current)
0.0
µ
A
Ramp UP 0.1s
Dwell 1.0s
Ramp DN 1.0s
Arc Sense 0
Continuity OFF
Max Lmt (Continuity)
1.00
Ω
Min Lmt (Continuity)
0.00
Ω
Offset (Continuity)
0.00
Ω
Connect OFF
IR
Voltage
1000V
Max Lmt
0M
Ω
Min Lmt
10M
Ω
Ramp UP 0.1s
Delay 1.0s
Ramp DN 1.0s
Connect OFF
