59
8. Options
Introduction
This section contains a list and descriptions of available factory installed options at the time of
this printing. The list of options contains an option code number that can be referenced on the
data plate on the rear panel of the unit.
Option Label
On the rear panel of the instrument, you will find a label that contains the option code.
For example, your options code would appear as follows:
Fitted with option 01 … .......................................................... OPT: 01
Fitted with option 01 and 02… ................................................ OPT: 0102
Hypot III Options
Option List
Code Description
01 High Resolution IR Limits
02 5mA Output Current
03
5Ω Continuity
04 PLC Ready Output
05 3mA Output Current
Description
01 High Resolution IR Limits
The High Resolution IR Limits option, increases the resolution of the Max and Min trip point
limits from 1MΩ to 0.1MΩ, in the range of 0.0 to 999.9MΩ.
The Max and Min Lmt set points automatically range while being edited according to the
specification table below. This is unique only to this feature because this option has multiple
ranges.
