67
10. Replacement Parts List
ECO: 4993 Rev.E
Part
Number
Qty. Reference
Designator
Description
35999 4 - Black Banana Jacks
37497 1 - Reset Switch, Red
37555 1 - Power Switch 2P 10A/250V
37571 1 - Earth Connector
37605 2 Fail, Ready Bulbs
37673 1 - Switch Test, Green
37783 1 RY1 Relay Gunther 3390-1290-246
37784 1 RY2 Relay Gunther 3392-1290-246
37880 1 3.15 Amp, fast acting 250VAC
38075 1 - Interlock Connector
38101 1 - Feet Kit w/o Rubber Inserts
38102 4 - Rubber Insert for Feet
36544 1 Adapter Box
38262 1 IC16 Microcontroller 78E516B PLCC
38367 1 CON 3670 Main Control Board
38264 1 HV 3670 High Voltage Board
38265 1 HRY 3670 HV Relay Board
38266 1 AMP 3670 Power Amplifier Board
38267 1 KEY 3670 Keypad Board
38268 1 PWR 3670 Input Voltage Select PCB
38271 1 - High Voltage Connector w/10cm cable
38272 1 - High Voltage Connector w/10cm cable
38287 1 T1 Input Transformer
38288 1 T2 Output High Voltage Transformer
38320 1 - 128 x 64 Graphic Display
04040A-08 1 - High Voltage Output cable
02100A-13 2 - Return cable
• For safety tester interconnect cables, refer to INSTRUMENT CONNECTIONS; section 1.3
Specific Integrated System Connections
