3. Specifications and Controls
3.1. Hypot III Functional Specifications
INPUT
Voltage
115/230 VAC ± 10%, user selectable
Frequency
50/60 Hz ± 5%
Fuse 3.15 Amp, fast acting 250VAC
DIELECTRIC WITHSTAND TEST MODE
Output Rating 5000V @ 20 mA AC
6000V @ 7.5 mA DC
Voltage Setting Range: 0 – 5.00KV AC
0 – 6.00KV DC
Resolution: 0.01KV
Accuracy:
± (2% of setting + 5V)
(Can be adjusted during operation.
Disabled when key lockout is active.)
Maximum Limit AC Range: 0.00 – 20.00 mA
Resolution: 0.01 mA
DC Range:
0 – 7500 µA
Resolution:
1µA
Accuracy:
AC and DC ± (2% of setting + 2 counts)
Minimum Limit AC Range: 0.000 – 9.999 mA
Resolution: 0.001 mA
DC Range:
0.0 – 999.9 µA
Resolution:
0.1 µA
Accuracy:
AC and DC ± (2% of setting + 2 counts)
Arc Detection Range: 0 – 9, 0 disabled
Failure Detector Audible and Visual
Ground Fault Interrupt
GFI Trip Current: 450µA max (AC or DC)
HV Shut Down Speed: <1ms
Voltage Display Range: 0.00 – 5.00KV AC
0.00 – 6.00KV DC
Resolution: 0.01KV
Accuracy:
± (2% of reading + 0.01KV)
