21
DIELECTRIC WITHSTAND TEST MODE
Current Display Auto Range
AC Range 1: 0.000mA – 3.500mA
Resolution: 0.001mA
Range 2: 3.00 – 20.00 mA
Resolution: 0.01 mA
DC Range 1:
0.0 µA – 350.0 µA
Resolution:
0.1 µA
Range 2: 0.300 mA – 3.500 mA
Resolution: 0.001 mA
Range 3: 3.00 mA – 7.50 mA
Resolution: 0.01mA
Accuracy: All Ranges
± (2% of reading + 2 counts)
DC Output Ripple
≤ 5% Ripple RMS at 6 KV DC @ 7.5 mA, Resistive Load
Discharge Time
≤ 200 ms
The maximum capacitive load vs output voltage :
0.20 µF --- < 1KV
0.10 µF --- < 2KV
0.06 µF --- < 3KV
0.050 µF --- < 4KV
0.040 µF --- < 5KV
0.015 µF --- < 6KV
AC Voltage Wave Form Sine Wave, Crest Factor = 1.3 – 1.5
Output Frequency Range: 50 or 60 Hz, User Selectable
Accuracy:
± 0.1%
Output Voltage Regulation
± (1 % of output + 5 volts)
from no load to full load and over input voltage range.
Dwell Timer Range: AC: 0, 0.3 – 999.9 sec (0 = Constant)
DC: 0, 0.4 – 999.9 sec (0 = Constant)
Resolution: 0.1 sec
Accuracy:
± (0.1% of reading + 0.05 sec)
Ramp Timer Range: Ramp-Up: 0.1 – 999.9 sec
Ramp-Down: AC 0.0 – 999.9 sec
DC 1.0 – 999.9 sec 0=OFF
Resolution: 0.1 sec
Accuracy:
± (0.1% of reading + 0.05 sec)
Ground Continuity
Current
DC 0.1 A ± 0.01A, fixed
Ground Continuity Range:
0.0Ω - 1.50Ω
Maximum Limit Resolution:
0.01Ω
Minimum Limit Accuracy:
± (3% of setting + 0.02Ω)
Ground Continuity Range:
0.0Ω - 0.50Ω
Auto Offset Resolution:
0.01Ω
Accuracy:
± (3% of setting + 0.02Ω)
