Associated Research hypot III 3670 User Manual

22
INSULATION RESISTANCE TEST MODE
Voltage Setting Range: 30 – 1000V DC
Resolution: 1V
Accuracy:
± (2% of setting + 5 volts)
Voltage Display Range: 0 – 1000 V
Resolution: 1V
Accuracy:
± (2% of reading + 2 counts)
Resistance Display Range:
1 – 9999 MΩ (4 Digit, Auto Ranging)
Resolution: 500VDC - 1000VDC
MΩ MΩ
0.001 1.000 - 9.999
0.01 10.00 - 99.99
0.1 100.0 - 999.9
1 1000 - 9999
Accuracy:
± (2% of reading + 2 counts) at test voltage
500 – 1000V and 1 – 999.9 MΩ
± (5% of reading + 2 counts) at test voltage
500 – 1000V and 1000 – 9999 MΩ
± (8% of reading + 2 counts) at test voltage
30 – 500V and 1 – 1000 MΩ
Maximum Limit Range:
0,1 – 9999 MΩ (0 = Off)
Resolution
1MΩ
Accuracy Same as Resistance display
Minimum Limit Range:
1 – 9999 MΩ
Resolution
1MΩ
Accuracy Same as Resistance display
Short Circuit Current Maximum: 9mAp
Ramp Timer Range:
Resolution:
Accuracy:
Ramp-Up: 0.1 – 999.9 sec
Ramp-Down: 1.0 – 999.9 sec 0=OFF
0.1 sec
± (0.1% of reading + 0.05 sec)
Delay Timer Range: 0, 0.5 – 999.9 sec (0 = Constant)
Resolution: 0.1 sec
Accuracy:
± (0.1% of reading + 0.05 sec)
Ground Fault Interrupt
GFI Trip Current: 450µA max
HV Shut Down Speed: <1ms
