63
9.2. Calibration Initialization
Press and hold the calibration key on the rear panel with a pen, pencil or small screwdriver
while powering ON the Hypot III. The Hypot III enters calibration mode after the power on
sequence is complete. The Calibration screens will appear as follows:
9.2.1. Calibration of Parameters
From the Calibration screens, use the “∨ “ soft key to scroll the Cursor to the parameter you
wish to calibrate. Once the cursor is pointing to the parameter you wish to calibrate, press the
Select soft key. A calibration prompt screen will now appear that describes the necessary load
and connection information for the parameter being calibrated.
The following is a list of the calibration parameters and an example of the prompt screen with
the details that will be displayed for each parameter (screen shown at left). Once you press
TEST, the Calibration data entry screen will appear for the selected parameter (screen shown at
right). Adjust the numeric value of the parameter using the “+” and “-” soft keys and press the
Enter soft key to accept the new parameter or press RESET to escape the edit.
Calibration of AC Hipot Voltage
Calibration
Connect the standard
5KVAC kilovolt meter
from H.V. to Return
<TEST> to Start
<RESET> to Exit
Calibration
+
Enter standard
Voltage reading
Voltage= XXXXV
_
<RESET> to Exit
Enter
Calibration
AC 5000V
DC 6000V
∨
IR 1000V
AC 20.00mA
Select
AC 3.500mA
(More)
Exit
Calibration
DC 7.50mA
DC 3.500mA
∨
DC 350 0uA
IR 999.9M
Ω
Select
IR 9999M
Ω
CONT 1.50
Ω
Exit
