Associated Research hypot III 3670 - Page 71

64
Calibration of DC Hipot Voltage
Calibration of IR DC Voltage
Calibration of AC Current 20.00mA range
Calibration of AC Current 3.50mA range
Calibration
+
Enter standard
Current reading
Current= XXXXV
_
<RESET> to Exit
Enter
Calibration
Connect the 100K
Ω
Load in series with
The 3.5mAAC standard
current meter.
<TEST> to Start
<RESET> to Exit
Calibration
Connect the 100K
Ω
load in series with
the 20mAAC standard
current meter.
<TEST> to Start
<RESET> to Exit
Calibration
+
Enter standard
Current reading
Current= XXXXV
_
<RESET> to Exit
Enter
Calibration
Connect the standard
1KVDC kilovolt meter
from H.V. to Return
<TEST> to Start
<RESET> to Exit
Calibration
+
Enter standard
Voltage reading
Voltage= XXXXV
_
<RESET> to Exit
Enter
Calibration
Connect the standard
6KVDC kilovolt meter
from H.V. to Return
<TEST> to Start
<RESET> to Exit
Calibration
+
Enter standard
Voltage reading
Voltage= XXXXV
_
<RESET> to Exit
Enter
