Associated Research hypot III 3670 User Manual

60
INSULATION RESISTANCE TEST MODE
Maximum Limit Range:
0.0 , 1.0 – 999.9 MΩ (0 = Off)
Resolution
0.1 MΩ
Range
1000 – 9999 MΩ
Resolution
1 MΩ
Accuracy Same as Resistance display
Minimum Limit Range:
1.0 – 999.9 MΩ
Resolution
0.1 MΩ
Range
1000 – 9999 MΩ
Resolution
1 MΩ
Accuracy Same as Resistance display
02 5mA Output
The 5mA Output option limits the output current with software control. The trip points are
adjusted to a maximum of 5mA and the software has been modified so the high-speed
maximum current shutdown is fixed at 5mA. The following specifications have been changed
for this option:
DIELECTRIC WITHSTAND TEST MODE
Output Rating 5000V @ 5 mA AC
6000V @ 5 mA DC
Maximum Limit AC Range: 0.00 - 5.00 mA
DC Range:
0 - 5000 µA
Minimum Limit AC Range: 0.000 - 0.500 mA
DC Range:
0.0 - 50.0 µA
03 5Ω Continuity
The 5Ω Continuity option increases the ground continuity maximum limit from 1.5Ω to 5Ω,
and increases the ground continuity offset range from 0.0Ω – 0.50Ω to 0.0Ω – 0.99Ω. The
following specifications have been changed for this option.
DIELECTRIC WITHSTAND TEST MODE
Ground Continuity
Maximum Limit
Minimum Limit
Range:
Resolution
Accuracy
0.0Ω – 5.00Ω
0.01Ω
±(3% of setting + 0.02Ω)
Ground Continuity
Auto Offset
Range:
Resolution
Accuracy
0.0Ω - 0.99Ω
0.01Ω
± (3% of setting + 0.02Ω)
