Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
44
Level 1
Level 2
Level 3
Setting item
Setting value
HDMI
InfoFrame/
Packet
Vendor
Specific
InfoFrame
3D Structure,
4: Quincunx O/L, O/R
Quincunx matrix
Odd/Left picture, Odd/Right picture
5: Quincunx O/L, E/R
Quincunx matrix
Odd/Left picture, Even/Right picture
6: Quincunx E/L, O/R
Quincunx matrix
Even/Left picture, Odd/Right picture
7: Quincunx E/L, E/R
Quincunx matrix
Even/Left picture, Even/Right picture
3DMeta Present
* Only displayed when Video
Format=3D is selected.
0: 0 (Not Present) / 1: 1
Metadata Type
* Only displayed when Video
Format=3D is selected.
0 (fixed)
Metadata Length
* Only displayed when Video
Format=3D is selected.
0 to 21
Metadata 1-21:
* Only displayed when Video
Format=3D is selected.
0x00 to 0xFF
The following is only displayed when IEEE RegID Sel=HF-VSIF is selected.
HF-VSIF Version
1 (fixed)
3D Valid
0 / 1
3D F Structure
* Only displayed when 3D Valid
= 1 is selected.
The output signal differs
from the standards. The DE
signal switches to HIGH for
the current Field alternative
Vblank3 interval.
0: Frame Packing
1: Field Alternative
2: Line Alternative
3: Side-by-Side (Full)
4: L + depth
5: L + d + G + G-d
( L + depth + graphics + graphics-depth )
6: Side-by-Side (Half)
7: Top & Bottom
3D F Ext Data
* Only displayed when 3D Valid
= 1 is selected.
3D Ext Data values “0 to 3”
are all switched to
“Horizontal sub-sampling”
in HDMI Ver.1.4a.
In VG, the previous notation
is included for
distinguishing rendering
methods in OPT Pattern 101
and compatibility.
0: Horizontal O/L, O/R
Horizontal sub-sampling
Odd/Left picture, Odd/Right picture
1: Horizontal O/L, E/R
Horizontal sub-sampling
Odd/Left picture, Even/Right picture
2: Horizontal E/L, O/R
Horizontal sub-sampling
Even/Left picture, Odd/Right picture
3: Horizontal E/L, E/R
Horizontal sub-sampling
Even/Left picture, Even/Right picture
4: Quincunx O/L, O/R
Quincunx matrix
Odd/Left picture, Odd/Right picture
5: Quincunx O/L, E/R
Quincunx matrix
Odd/Left picture, Even/Right picture
6: Quincunx E/L, O/R
Quincunx matrix
Even/Left picture, Odd/Right picture
